INSTALLATION
Pump Location
5
Pump Location
IMPORTANT: If high pressure units are installed, the high pressure pump must be placed second in the
flow path.
• Install the pump in a clean, dry, and ventilated location shielded from direct sun and precipitation.
• Provide adequate room for future servicing, protection from freezing temperatures, flooding, and
equipment drainage.
• Bolt unit down evenly on a good foundation, preferably concrete, to prevent unnecessary stresses from
pump movement.
• Install as close as possible to water source to minimize suction piping length.
Piping Instructions
• Ensure piping matches the pump inlet and outlet connection sizes.
• Calculate the maximum distance allowable between the pump and water source, and pipe accordingly.
• For long runs, increase connections by one pipe size.
• The use of pipe thread sealant is recommended.
• Use flexible hoses or expansion joints.
• Avoid the use of unions on the suction line if possible.
• Do not over-tighten piping connections.
• Include a gate valve and check valve in the discharge line.
Suction Line
• Set up piping in suction lift applications to rise vertically, or in a continual slope of 2° or greater, from
the water source.
• Ensure there are no high spots that cannot be evacuated of air during the priming process.
• All suction line connections must be airtight.
• Include a gate valve.
Risk of bodily injury or damage to pump or other equipment.
• Check that lifting equipment complies with all safety rules, and is suitable to support the weight of the pump.
Risk of damage to pump or other equipment.
• Properly support all suction and discharge piping to avoid strain on the pump.
