13
ENGLISH
Engine NEF 67 SM - TM
1. Coolant filler cap - 2. Heat exchanger - 3. Lubricant oil filler cap
- 4. Engine air inlet manifold - 5. Waste-gate - 6. Oil vapour bleeder
- 7. Lifting U-bolt - 8. Air filter - 9. Injection pump - 10. Fuel outlet
connector to tank - 11. Fuel inlet manifold from tank - 12. Hand
pump - 13. Oil dipstick - 14. Fuel filter.
*) Excluding versions SM
EngineNEF 67 SM - TM
1. Exhaust manifold - 2. Turbocharger air intake - 3. Turbocharging air
outlet - 4. Turbocharger - 5. Exhaust gas discharge - 6. Lifting U-bolt
- 7.Coolant outlet manifold from engine - 8. Thermostat valve
location - 9. Fan - 10. Auxiliary member drive belt - 11. Alternator -
12. Engine coolant inlet sleeve - 13. Lubricant oil discharge plug - 14.
Oil filter - 15.Electrical starter motor.
*) Excluding versions SM
   
       
05_605_N

       
05_606_N
