ENGINE TECHNICAL DATA N67 MNA/MSA/MNT/MST
The technical code and serial number are indicated on a plate, which
is located on different parts of the engine, according to the model:
flywheel casing, tappet cover, other.
(1) Excluding engines N67 MNA / MSA
(*)Net power to the flywheel in compliance with ISO 3046-1. Test
conditions: temperature 25 °C; atmospheric pressure 100 kPa;
relative humidity 30%.
Code N67 MNA/MSA/MNT/MST
Engine family F4
Cycle 4-stroke diesel
Number and arrangement
of cylinders 6, in line
Bore x stroke 104 x 132 mm
Total displacement 6,700 cm
3
Air system Supercharged and aftercooled
(1)
Injection type Direct with rotating pump
Engine direction of rotation Anticlockwise (seen from flywheel
side)
Dry weight 530 kg
Electrical system 12 V
Accumulator/s
- capacity
- discharge current
180 Ah or above
950 A or above
Performance TIER2 Maximum power (*)
Maximum torque
N67 MNA / MSA 81 kW (110 CV) @ 2500 rpm
440 Nm (45 Kgm) @ 1400 rpm
N67 MNT / MST 120 kW (163 CV) @ 2300 rpm
630 Nm (64 Kgm) @ 1400 rpm
N67 MNT / MST 129 kW (175 CV) @ 2300 rpm
700 Nm (71 Kgm) @ 1400 rpm
Performance TIER3 Maximum power (*)
Maximum torque
N67 MNT 129 kW (175 CV) @ 2200 rpm
720 Nm (73 Kgm) @ 1400 rpm
WARNING
Any alteration of the above mentioned characteristics is strictly
prohibited, penalty invalidation of the guarantee and absence of all
liability on the part of IVECO MOTORS.
