Some batteries have a single cover for the inspection plugs. To access
the elements, use a lever as shown in the figure.
Check condition of the blow-by filter
Only proceed when the engine is not turning over.
Disconnect the oil vapour recovery pipe from the blow-by filter (2).
Remove the screws (1) and detach the blow-by filter (2) from the
cylinder tappet cover 5-6 (3); retain the seal.
Check that the blow-by filter (2) is not clogged; Otherwise replace it.
Clean the contact surfaces carefully.
Install the seal and fit the blow-by filter (2) on the cylinder tappet cover
5-6 (3).
Tighten the screws (1).
ATTENTION!
During the checks do not smoke or allow naked flames
near the batteries. Ensure that the work area is suitably
ventilated.
