Operating instructions
Parquet floor sander COBRA C
with gentle lifting lever
37
9 Parts lists
9.1 Parts list of chassis
Quantity
Part No. Article No. Designation per machine
1,00 370001000 machine housing 1
3,00 370003000 guide tube support 1
3,01 912008025 screws 4
3,02 679808000 serrated washers 4
3,03 933008055 clamping screws 1
3,05 011008016 lock nut 1
3,06 099008063 clamping handle 1
3,07 125008000 washer 1
4,00 370004000 pressure regulating screw 1
6,00 370006000 cover lock 1
6,01 963004008 screws 2
6,02 370006000 lock notch 1
6,03 963004008 screws 2
7,00 938008085 screw bolt 1
7,01 934008000 lock nuts 2
7,02 466008000 knurled nut 1
8,03 370008030 drum cover 1
8,06 912006020 screw 1
8,07 934006000 lock nut 1
9,00 370009000 hinges (female part) 2
9,01 936006000 lock nuts 2
10,00 370010000 hinges (male part) 2
10,01 936006000 lock nuts 2
11,00 310002050 bumper wheel 1
11,01 912006035 screw 1
11,02 125006000 lock nuts 2
11,03 934006000 washers 2
12,00 310012000 bumper wheel support 1
12,01 912006020 screw 1
12,02 125006000 washer 1
13,00 370013000 sanding drum 1
14,00 370014000 tension roller holder 1
14,01 036264100 pressure spring 1
14,02 310014020 pressure piece 1
14,03 691210050 screw 1
14,04 934010000 lock nut 1
14,05 310014050 tension lever 1
14,06 370014050 grip 1
14,07 691208045 screw 1
14,08 936008000 lock nut 1
14,09 310014090 axle 1
14,10 799108030 screw 1
14,11 444008080 adjusting screw 1
14,12 934008000 adjusting nuts 2
14,13 934008000 lock nut 1
14,14 440008028 washer 1
14,15 912008030 screw 1
14,16 679808000 serrated washer 1
15,00 370015000 tension roller shaft 1
