Franke FDW 4510 E8P E - User Guide Overview; Appliance Overview; Control Panel Explanation

4
Before using the appliance carefully read Safety Instructions guide.
OVERVIEW
1 2 3 4 5 6 7 8 9 10
11
CONTROL PANEL
1. ON-OFF/Reset button with indicator light
2. Program selection button
3. Salt rell indicator light
4. Rinse Aid rell indicator light
5. Program number and delay time indicator
6. Tablet indicator light
7. Display
8. Multizone indicator lights
9. Multizone button
10. Delay button
11. START/Pause button with indicator light / Tab
USER GUIDE
1
2
3
4
5
7
8
10
9
13
0000 000 00000
Service: 1112
6
1. Upper rack
2. Foldable aps
3. Upper rack height adjuster
4. Upper spray arm
5. Lower rack
6. Space Zone
7. Cutlery basket
8. Lower spray arm
9. Filter Assembly
10. Salt reservoir
11. Detergent and Rinse Aid dispensers
12. Rating plate
13. Control panel
