Franke MARIS Series User Manual

– 5 –
FHMA 604 3G DC / FHMA 755 4G DC/DCL / FHMA 905 4G DCL / FHSM 604 3G DC
FHSM 604 4G / FHSM 755 4G DC / FHSM 905 4G DCL
EN
Z
Do not use steam cleaners
or direct jets of water.
Z
Never use scouring pads,
steel wool, muriatic acid or
other products which could
scratch or mark the surface.
Z
Never use sharp objects,
as they could damage the
seals between the trim and
worktop.
Z
Ensure the gas outlet zones
are perfectly clean.
Z
These instructions are only
valid if the country symbol
appears on the appliance.
If the symbol does not
appear on the appliance,
it is necessary to refer to the
technical instructions which
will provide the necessary
instructions concerning
modification of the appliance
to the conditions of use of
the country.
Risk of fire!
Z
Do not store items on the
cooking surfaces.
WARNING: Unattended
or automatic cooking on a hob
with fat or oil can be dangerous
and may result in fire. Hot oil
ignites readily.
TECHNICAL DATA
1
3
2
2
2
4
4
1
2
2
2
1
3
1
3
4
3
2
2
2
2
1
4
FHSM 604 4G
FHMA/FHSM 604 3G DC FHMA 755 4G DCL FHSM/FHMA 4G 755 DC FHMA/FHSM 905 4G DCL
Position Burner Rated
Capacity -
G20
Injectors
G20 -
20 mbar
Rated
Capacity -
G30
Rated
Capacity -
G31
Injectors G30/
G31 28-30/
37 mbar
Rated
Power
(Kw)
Reduced
Power (Kw)
4 DC 0,315 1,35
240 240 0,91 3,3
2,10
*218 *218 *0,85 *3
3 R 0,286 1,15 218 218 0,85 3 1,30
2 SR 0,166 0,97 127 127 0,65 1,75 0,70
1 AUX
0,095 0,72 73 73 0,50 1 0,65
Pressure
(mbar)
min 17 20 25
nom 20 28-30 37
max 25 35 45
Type of Gas G20 natural gas
LPG
G30 Butane
G31 Propane
Cat. II
2H3+
*ALL FHMA MODELS
