Franke Kaffeemaschinen AG Usage | 3
User manual SU12/UT12 15
3.4 Components of the cooling unit
The device is available with different features and configurations. The images
shown are for reference only, the actual product may vary.
1
3
4
5
6
2
7
8
1 On/off switch for cooling unit 2 Temperature display and temperature control
3 Switch for milk/cleaning mode 4 On/off switch for heated cup tray (SU12)
5 Cleaning agent cartridge 6 Milk/medium container (1x12l or 2x4.5l)
7 Reversible adapter (milk feed/cleaning) 8 Heated cup tray (SU12)
