ICA100 Rev171109
10
To Remote
Station
Figure 5. ICA200 Wiring
Remote Station
Master Station
GND
+12 VDC
Fuse
3 AMP
3 Pin
Molex Connector
Wiring
White
Yellow
Black
If the PTT option is installed
on the remote station a 5-pin
Molex will be used.
