Figure 7. ICA400/500 Mounting Dimensions
Master Station
Cutout and
Mounting Holes
Remote Station
Cutout and
Mounting Holes
Suggested Panel Opening
5 1/8" H x 5 1/8" W
Suggested Panel Opening
6 3/8" H x 5 1/8" W
Drill the holes for number 10
mounting hardware.
6 3/4"
5 1/2"
5 1/2"
5"
12
14
