22
59. Attach a Leg Developer Strap (43) to the Leg
Developer (10) with an M8 x 12mm Button
Shoulder Screw (83).
Attach the other Leg Developer Strap (43) in
the same manner.
60. Make sure that all parts have been properly tightened. The use of the remaining parts will be explained in
ADJUSTMENTS, beginning on the following page.
Before using the weight system, pull each cable a few times to make sure that the cables move smoothly
over the pulleys. If one of the cables does not move smoothly, find and correct the problem. IMPORTANT: If
the cables are not properly installed, they may be damaged when heavy weight is used. See the
CABLE DIAGRAMS on pages 28 and 29 of this manual for proper cable routing. If there is any slack
in the cables, you will need to remove the slack by tightening the cables. See TIGHTENING THE
CABLES, starting on page 25 in the ADJUSTMENT section.
59
83
43
10
