Amperage 32A
Polarity 3P+N+PE
Nominal Voltage 400 V
Frequency 50 Hz
Reference Standard IEC 60309-1, IEC 60309-4
Poles reference 6h
IP grade IP55
Once the installation on the wall has been completed, to connect the eProfessional to the
electric network, simply insert the plug into a suitable electrical socket. If not present, proceed
with the installation of the socket in proximity of eProfessional. For the installation, please refer
to the plug specic instructions.
The equipment must be powered by connecting the three-phase plug with a compliant
three-phase socket according to EN 60309-1 and EN 60309-2 standards.
The charger’s electrical data, which should be referred to in order to determine the correct size
of the power supply system, are shown on the charger’s identication label (see chapter 2.1.).
A socket (female connector) installed close to eProfessional is required, having the following
requirements:
Both wall-mounting and switchboard-mounting versions of the socket are acceptable.
