Freedom R8000 Series User Manual

AutoTune for Motorola APX Series Radios User Guide
52
6.16. P25 Phase II Modulation Fidelity
NOTE: This test requires an analyzer with P25 Phase 2 Test Mode (R8-P25_II
option) capability.
The purpose of this procedure is to measure the radio transmitter’s P25 Phase 2
Modulation Fidelity at a given frequency. Modulation Fidelity represents how accurately
a P25 Phase 2 transmitter reproduces an ideal theoretical modulation waveform. The
TIA/EIA-102.CCAB measurement standard max limit is 5%. This is a test only; there is
no alignment.
Mode
Port
Frequency
Mon Mod Type
Test Pattern
Monitor
RF IN/OUT
Test Frequency
HCPM
1031 Hz Tone
Table 6-30. Analyzer Configuration for P25 Phase 2 Modulation Fidelity test
6.16.1. Test
The analyzer is setup as specified in this section’s Analyzer Configuration table. The
radio is placed into Test Mode at the lowest Tx Test Frequency and configured to
generate the indicated P25 Phase 2 waveform signal. The analyzer measures the
Modulation Fidelity response which is compared against test limits and the final results
are written to the log file.
Name
Description
Result
Pass or Fail. Modulation Fidelity error within Max Limit
Frequency
Test Frequency
Mod Fi
Measured RMS error (%) at Frequency normalized across symbols
Max Limit
Maximum Limit (inclusive) for Modulation Fidelity to Pass
Table 6-31. P25 Phase 2 Modulation Fidelity test results
