3. Replace props and nylon washers if required.
4.
Refit top plate and attach with (2x) M5x30 bolts and (4x) M3x10 bolts.
Loctite 243 or equivalent must be used to secure these fasteners.
5. Reinsert the ActiveBlade bumpers as detailed in the previous section.
{% hint style="warning" %} Props are supplied as a weight matched and balanced pair. Only
fit props in the factory supplied pair. {% endhint %}
****
Replacing ActiveBlades
1.
Remove (x4) M3x10 bolts by accessing through the top of the assembly
as shown.
2.
Fit new assembly and secure with (x4) M3x10 bolts. Loctite 243 or
equivalent must be used to secure these fasteners.
Opening Chassis
1.
Set aircraft on a stable level work surface.During disassembly, take care to note the
location of fasteners and orientation of parts, as this will greatly help with reassembly.
2.
Remove the following fasteners:
1.
(x4) M4x16 Combo - which secure the boom stays to the boom
2.
(x4) M3x10 FHCS - which secure the closeout panels
3.
(x4) M3x10 Combo - which secure the closeout panels
4.
(x2) M3x10 Combo - which secure the battery connector mount
5.
(x2) M3x10 Combo - which secure the center ring
6.
(x4) M4x14 Combo - which secure the center ring
7.
Remaining M4 bolts that secure the top chassis to each hinge
3.
The top chassis can now be removed from the machine, and the inner cover lifted off
to access the enclosure area.
