FPV Camera and Transmitter
FPV System installation
1.
Connect the FPV camera cable to the FPV extension located inside the
chassis at the base of boom.
2.
Screw the FPV mount to the top of the chassis with the (x4) M3x14
screws and washers.
3.
Screw the FPV camera bracket to the FPV mount with (x2) M2.5x5
screws and washers.
