Freeform F20 - Page 17

PARTS LIST
1 Base Frame
1
42 Allen M8*40
2
2 Main Frame
1
43 Allen M8*40
2
3 Computer Bracket
1
44 Allen M8*45
3
4 Left Upright
1
45 Allen M10*30
2
5 Right Upright
1
46 Allen M6*55
2
6 Motor Bracket
1
47 Allen M6*45
1
7 Fixing pin
2
48 Allen M6*35
6
8 Turnning Bushing
2
49 Bolt ST4.2*20
4
9 Front Roller
1
50 Bolt M5*8
14
10 Rear Roller
1
51 Rubber cushion
4
11 Wrench w/ screw driver S=13
、
14
、
15
1
52 Bolt ST4.2*12
11
12 5# Allen Wrench 5mm
1
53 Bolt ST4.2*25
2
13 Cylinder
1
54 Washer 6
3
14 Console top cover
1
55 Washer 8
14
15 Motor top cover
1
56 Washer 8
6
16 Motor bottom cover
1
57 Flat washer C 8
7
17 Lefe rear cover
1
58 Big washer C φ10*φ26*2.0
2
18 Right rear cover
1
59 Control board
1
19 Side rail
2
60 Handpulse with
start/stop
1
20 Running belt
1
61 Top signal wire
1
21 Motor belt
1
62 Middle signal wire
1
22 Console panel
1
63 Low signal wire
1
23 Blue cushion
2
64 Fliter Optional
1
24 Square cushion
4
65 DC Motor
1
25 Ring protecting wire plug
2
66 Safety accessory
1
26 Moving wheel
2
67 AC single line Blue
1
27 Power wire buckle
1
68 AC single line Brown
2
28 Foot pad
4
69 Power wire
1
29 Adjustable foot pad
2
70 Running board
1
30 End cap
2
71 Square switch
1
31 Foam
2
72 Bolt ST3.5*12
3
32 EVA
cushion
2
73 Magnetic ring
1
33 Left upright tube cover
1
74 Magnetic core
1
34 Right upright tube cover
1
75 Holder Optional
1
35 Bolt M6
2
76 Bolt M8*35
2
36 Bolt M8
6
77 Bolt ST4.2*12 12
37 Inductance Optional
1
78 Handpulse with speed 1
38 Bolt M8*35
1
39 Allen M8*15
12
40 Allen M8*20
4
41 Allen M8*30
1
