Freeform F20 - Assembly Steps Part 1; Initial Assembly Steps

Notice: Do not connect power before assembly completion
Step 1:
Step 2:
Step 3:
Open the carton, take out the above
spare parts and put the main frame on
the level ground.
Lift up the console A and upright tube B
with the arrow direction.
Notice: When you lift up A and B, make
sure do not press the wires inside the
upright tubes; Hold the upright tubes
and console by hand to prevent any
accident.
Fix the upright tubes to the main frame
with M8*15 allen (39) and washer (55) by
using 5# Allen wrench(12).
Notice: Support the Upright Tube with
hand to avoid falling down.
B
A
