PARTS LIST
No. Description Specification Q’ty No. Description Specification Q’ty
1 BASE FRAME 1 52 BLUE RUBBR CUSHION 2
2 MAIN FRAME 1 53 ADJUSTABLE WHEEL 2
3 INCLINE FRAME 1 54 CONE-SHAPE CUSHION 2
4 COMPUTER FRAME 1 55 FLAT FOOT PAD 6
5 MOTOR BRACKET 1 56 WIRE PROTECTOR 2
6 LEFT UPRIGHT TUBE 1 57 THREAD AXLE 2
7 RIGHT UPRIGHT TUBE 1 58 SPEED SENSOR 1
8 BOLT M5*16 6 59 AC SINGLE WIRE BLUE 1
60 AC SINGLE WIRE BROWN 2
10 FRONT ROLLER 1 61 GROUNDING WIRE 1
11 BACK ROLLER 1 62 MAGNET RING 1
12 CYLINDER 1 63 MAGNET CORE 1
13 BUSHING 4 64 POWER WIRE 1
14 PLASTIC PAD 4 65 5# ALLEN WRENCH 5mm 1
15 TRANSPORT WHEEL PLUG 4 66 WRENCH W/SCREW
DRIVER
S=13
、
14
、
15 1
16 TRANSPORT WHEEL 2 67 BOLT M8 6
17 RUNNING BOARD 1 68 BOLT M10 6
18 COMPUTER TOP COVER 1 69 BOLT T2.9*6.5 16
19 COMPUTER PANEL 1 70 SCREW M8*15 12
20 BOLT M5*12 2 71 SCREW M8*20 6
21 CUSHION PAD 4 72 SCREW M8*30 1
22 ANTI-SLIP PAD OPTIONAL 2 73 SCREW M8*42 1
23 LEFT UPRIGHT TUBE COVER 1 74 SCREW M8*40 2
24 RIGHT UPRIGHT TUBE
COVER
1 75 SCREW M8*40 2
25 LEFT BACK END COVER 1 76 SCREW M8*70 2
26 RIGHT BACK END COVER 1 77 SCREW M8*80 2
27 MOTOR TOP COVER 1 78 SCREW M10*30 4
28 MOTOR BUTTON COVER 1 79 SCREW M10*45 1
29 80 SCREW M10*60 1
30 SIDE RAIL 2 81 SCREW M8*45 1
31 SAFETY KEY MAGNETIC
SENSOR
1 82 SCREW M8*35 1
32 AC SINGLE WIRE BLUE 1 83 SCREW M6*55 3
33 AC SINGLE WIRE BROWN 1 84 SCREW M6*35 2
34 PIPE END CAP 2 85 SCREW M6*25 6
35 SPEAKER NET 1 86 SCREW M5*12 8
36 87 SCREW M5*8 15
37 SAFETY KEY 1 88 SCREW ST4.2*12 12
