78mm
(3-1/8")
13
ESC
Item No.
KV
Value
Volate
(V)
Current
(A)
Pull
(g)
Motor
Resistance
Weight
(g)
No Load
Current
Propeller
1550RPM/V
22.2
95
3600
0.02
195
2.7A/10V
95A
90mm
Ducted Fan
MO 03748
18.45mm
12.5mm
M3.0 (4pcs)
54.29mm
47.29mm
20.35mm
36.9mm
6.0mm
M3.0
Item No.:FJ310
F-104S Starfighter
Lift up tape and remove the
battery compartment cover
EN
Battery Installation
Battery hatch space size: 60
x
27
x
10mm
Before connecting a battery to the ESC, please
switch on the transmitter power and make sure
the throttle stick is in the lowest position.
Engaged the kill switch if you have one
assigned.
Battery compartment cover
Battery
Battery tray
Velcro
Center of Gravity
After installing the battery, use
the Velcro strap to lock it in.
NOTE：This motor is a special product for use only with the Freewing 90mm 12-blade ducted fan P090
2.
Conversely, the 90mm 12-blade ducted fan P0902 is not for use with any other motors!
Motor parameters
R
The recommended battery capacity and discharge
rate is:
The correct Center of Gravity is directly related to the
success of the initial flights. Refer to the following
diagram to ensure you have the proper CG. Once
comfortable with the airplane, you can adjust the CG to
suit your individual taste.
You can adjust the CG by moving the
battery either forward or back. If you find
that moving the battery is insufficient,
you can use some other suitable material
such as a sticky back weight strip to
counter weight.
