Item No.:FJ310
F-104S Starfighter
12
11
Servo lntroduction
A servo or reversed servo is defined as follows:
When the servo input signal changes from 1000ųs to
2000ųs, if the servo arm rotates clockwise, it's a positive
servo. If it rotates counter clockwise, it's a reversed servo.
lf you choose to purchase another brand of servo,please refer to the following list to ensure that it is the correct size and type.
LED light(Single flashes)
Air-brake servo
Throttle (ESC)
External UBEC access port
Afterburner access port
Flap servo
Gear
Air-brake
Air-brake
Air-brakeAir-brake
Air-brake
FLAP
FLAP
FLAP
Landing Light
Landing Gear
Cabin door servo
Landing Light
Gear
Afterburner
UBEC cable
ESC throttle cable
Throttle
Cabin door
Receiver
Connect receiver air- brake channel
Connect receiver throttle channel
Connect receiver flap channel
Connect receiver landing gear channel
Control Board Introduction and Use
EN
1
2
3
4
5
6
9g-MG
17g-MG
17g-MG
17g-MG
17g-MG
17g-MG
No.
Pos./Rev.
400mm
150mm
180mm
180mm
120mm
120mm
Reverse
Positive
Positive
Positive
Positive
Reverse
lnstalling position
Nose gear door
Nose
gear steering
Aileron(L)
Aileron(R)
Flap(L)
Flap(R)
Servo cable length
Specification
650mm
650mm
250mm
250mm
400mm
360mm
No.
lnstalling position
Pos./Rev.
7
8
9
10
11
12
16g-MG
16g-MG
9g-MG
9g-MG
17g-MG
17g-MG
Reverse
Positive
Positive
Reverse
Positive
Positive
Servo cable length
A L)
Air-brake(R)
Elevator
Rudder
ir-brake(
Rear gear
door(L)
Rear gear
door(R)
Specification
special use
Strobe light
According to the noted, connect the servo cable or LED light cable to the correct access port.
