( 3.78in)
96mm
Please assemble and disassemble the nose gear by referring to the following photo.
Accessories name and specification
A- electric retract
B- Nose gear steering pushrod
C- Nose gear steering control ring
D- Nose gear metal shaft
E- L-shape arm
F-Grub screw
G-Grub screws
H-Nose landing gear main strut
I-Screw
(M3×3mm 1pc)
(M4×4mm 2pcs)
(PM2×3mm 1pc)
Nose gear assembly installed
Screws(PWA3x12 4pcs)
Nose gear mount
PQ
R
S
T
R1
S1
U
V
X
W
AB
3
Nose Gear Assembly
A
B
C
D
E
1
F
Step
G
H
I
K
J
M
L
N
O
2
Step
Step
M-Screw
N-Spring
O-Damping lever
P-Screw
Q-LED light
R-Pin
J-Screw(PM2x4mm) K-
LED light attachment arm
L-U-shape damping arm.
(PM2x3mm)
(PA2×8mm)
(Ø3.5x9.2mm)
S-
T-
U-
V-
W-
X-
AB-
E-clip
8-shape connecting arm
Pin
U-shape slant supporting rod
Wheel shaft
E-clip
Wheel
(Ø1.5mm)
(Ø3.5x11.3mm)
(Ø5x25.5mm)
(Ø2mm)
(Ø45x16mm)
Nose steering pushrod size
Servo pushrod installing hole
Rotating the pushrod,will increase
or reduce it's length.
Pushrod diameter:Ø1.5mm
Landing gear Installation
EN
Nose gear servo Installation
R
A- Screws (PMA2x8mm 2pcs)
B- Servo
C- Landing gear pushrod
D- Nose gear hard point
