02/01/2011 f490450
1
2
3
4
5
6
7
8
9
10
11
12
1. ATD
2. DOC Inlet Temperature Sensor
3. DPF Inlet Temperature Sensor
4. DPF Outlet Temperature
Sensor
5. DEF Injector
6. NOx Sensor
7. SCR Outlet Temperature
Sensor
8. SCR Catalyst
9. SCR Inlet Temperature Sensor
10. Mixer Tube
11. DPF Outlet Pressure Sensor
12. DPF Inlet Pressure Sensor
Fig. 5, Cummins 2HH ATS (with Sensor Locations)
Exhaust 49
108SD and 114SD Maintenance Manual, December 2015 49/7
