3. Slide the air filter out of the sleeper HVAC as-
sembly. See Fig. 8.
4. Discard the air filter.
5. Place a new air filter in the sleeper HVAC as-
sembly. The edge of the filter should be flush
with the HVAC assembly.
6. Lower the bunk panel and mattress.
7. Remove the chocks from the tires.
04/15/98
f831227
1
2
3
A
A. The arrow on the filter should point toward the HVAC assembly.
1. Sleeper HVAC Assembly
2. Screen
3. Filter (pleated-paper filter shown)
Fig. 7, Sleeper HVAC Assembly, Water-Valve Controlled
02/26/2002
f831492
1
1. Air Filter
Fig. 8, Sleeper HVAC Assembly, Blend Air
Heater and Air Conditioner 83
Century Class Trucks Maintenance Manual, April 2003 83/5
