9.4 After cleaning, connect the cables to the
batteries, and tighten them to the torque
specifications listed on the battery, gener-
ally 10 to 15 lbf·ft (14 to 20 N·m).
9.5 Spray each connection with dielectric red
enamel and coat the battery terminals
with dielectric grease; see Table 1.
Approved Dielectric Protectants
Protectant Material Approved Brand
Dielectric Grease Lubriplate FLP DS–ES
Dielectric Red Enamel
Spray-On Application
3M 1602 IVI-Spray Sealer; order
from the PDC
Spray-On B–6–665
Dielectric Red Enamel
Brush-On Application
Gyptal 1201EW-Low VOC, Red;
order at www.glyptal.com or
1-800-GLP-1201
Table 1, Approved Dielectric Protectants
10. Check the terminals on the battery shut-off
switch and the magnetic switch. Make sure the
terminal connections are clean and tight. Coat
the terminal connections with dielectric red
enamel after cleaning.
Alternators and Starters15
Century Class Trucks Maintenance Manual, January 200615/2
