Status display
The switch clock has acontrol LED in the
instant start button which signals the current
state of the auxiliary heating.
The colors in which the control LED lights up/
flashes have the following meanings:
R
white -heater switched off/control panel
activated
R
green -heating mode enabled
R
green flashing -heating mode program time
activated
R
red -malfunction
If the heater is switched off, the switch clock
switches to the idle state 60 seconds after the
last operation. The display and the status dis-
play are then switched off automatically.
Back function
The back function serves to quit aselected
menu or menu item.
X
Turn the controller counter-clockwise until
"Back" is shown in the display.
X
Press the controller.
The settings will be saved.
The higher menu level is shown in the dis-
play.
Setting the time and day of the week
Turn the controller to select afunction or
make asettingand confirm the selection/
settingbypressing the controller.
X
To set the day: select the "Settings" menu
and confirm.
X
Select the "Day" menu item and confirm.
X
Set and confirm the day of the week.
X
To set the time: select the "Settings" menu
and confirm.
X
Select the "Time" menu item and confirm.
X
Select and confirm the time format (12 or
24 hours).
The time flashes on the display.
X
Set and confirm the hours.
The minutes display flashes in the display.
X
Set and confirm the minutes.
Setting the instant start
The instant start button is used to start the
heating mode without having to make any fur-
ther settings.
The instant start can be set in the "Settings"
menu.
Turn the controller to select afunction or
make asettingand confirm the selection/
settingbypressing the controller.
X
Select the "Settings" menu and confirm.
X
Select the "Instant start" menu item and
confirm.
The set operating mode is displayed.
X
Select the 'Heating" function and confirm.
The operating time flashes on the display.
X
Set and confirm the desired operating time
(hour).
The minutes display flashes in the display.
X
Set and confirm the desired operating time
(minute).
The selected settings are stored for the
instant start button.
Switching instant starton/off
X
To switch on: press the instant start but-
ton.
The display shows the "Heating" function
and the set remaining time.
The control LED in the instant start button
lights up green.
X
To switch off: press the instant start button
again.
The heating mode is switched off.
The control LED lights up white.
Switching the heating mode on/off in
the menu
Turn the controller to select afunction or
make asettingand confirm the selection/
settingbypressing the controller.
X
To switch on: select the "Heating" menu
and confirm.
The operating time flashes on the display.
X
Set and confirm the desired operating time
(hour).
The minutes display flashes in the display.
X
Set and confirm the desired operating time
(minute).
The heating mode is started.
The display shows the "Heating" function
and the set remaining time.
