Monitoring info menu
Reservoir pressure menu window
X
To display the reservoir pressure: use the
u or t button to scroll to ã moni-
toring info.
The menu windowshowsthe reservoir pres-
sure of brake circuits \ and ^ as a
bar display.
Engine menu window
In the EngineEngine menu window, you can check
the engine oil leveland display the engine's
operating hours.Check the engine oil level
before the start of every journey.The engine
oil levelisnot displayed while driving.
X
Park the vehicleonalevelsurface.
X
Apply the parking brake.
X
Switch off the engine.
X
Turn the key to the drive position in the igni-
tion lock.
X
Waitatleast five minutes after switching off
the engine.
i
If you call up the oil leveltoo earlyorwhile
the engine is running, Not availableNot available
appears in the menu window.
X
Use the u or t button to scroll to ã
monitoring info.
X
To display the engine oil level and oper-
ating hours: use the r or s button
to scroll to the EngineEngine menu window.
The menu windowshows:
R
the 4 engine oil level, e.g. Top upTop up
oil: 1USgaloil: 1USgal
R
the ý operating hours of the engine,
e.g. 10000 h27min10000 h27min
The service counter is not suitable for
measuring the driving hours of the driver.
Use equipment which is suitable for this
purpose.
X
If Oil level lowOil level low or Oil level too lowOil level too low
is displayed in the menu window, immedi-
ately top up the amount of oil displayed
(Y page163) and call up the oil levelagain.
i
If the oil levelistoo low,donot start the
engine.
X
If the oil leveldisplay is not available,repeat
the oil levelcheck.
X
If it is not possible to display the oil level
after repeated attempts, have the oil level
display checked at aqualified specialist
workshop.
Coolantmenu window
X
Use the u or t button to scroll to ã
monitoring info.
X
To display the coolanttemperature: use
the r or s button to scroll to the
CoolantCoolant menu window.
i
If the coolant levelistoo low,the coolant
temperature cannot be displayed.
Events menu window
You can display stored malfunctions and mes-
sagesinthe EventsEvents menu. If you have recti-
fied the causeofthe malfunction/message,
the on-board computernolonger displaysthe
event.
X
Use the u or t button to scroll to ã
monitoring info.
X
Use the r or s button to scroll to the
EventsEvents menu window.
The menu windowshows, for example, the
number of events.
X
To display an event: press 9.
X
To display further events: use the r or
s button to show the next event win-
dow.
Diagnosticsmenu window
Diagnostics data contains information with
which you can assist the workshopstaff during
fault diagnosis, e.g. via roadside assistance.
The DiagnosisDiagnosis menu windowcontains, for
example, alistofall control units (systems)
installed in the vehicle. You can obtainfurther
information from any Freightliner service cen-
ter.
X
Use the u or t button to scroll to ã
monitoring info.
X
Use the r or s button to scroll to the
DiagnosisDiagnosis menu window.
X
To display diagnostics data: press 9.
The inputwindowshowsalistofall control
unit system abbreviations.
