Actuator Stroke–Standard Stroke
Brake Actuator Size
Recommended Maximum
Operating Stroke (Inches)
24 1-3/4
20 1-3/4
16 1-3/4
12 1-3/8
Table 3, Actuator Stroke–Standard Stroke
Actuator Stroke–Long Stroke
Brake Actuator Size
Recommended Maximum
Operating Stroke (Inches)
30 Long Stroke 2-1/2
24 Long 2
24 Long Stroke 2-1/2
20 Long 2
16 Long 2
Table 4, Actuator Stroke–Long Stroke
Brakes 42
Business Class M2 Plus Maintenance Manual, 02/10/2023 42/19
