2019 Amazon P80 Package Delivery Vehicle
Headlight Replacement:
1. Remove screws and trim ring from around headlight.
2. Remove headlight.
3. Remove wiring plug from back of headlight.
4. Replace headlight.
5. For installation reverse removal sequence.
Tail, Turn Backup and Marker Lamp Replacement:
1. Push tail, turn back-up lamp into rubber grommet and use a small at head screw
driver and pry lamp from rubber grommet.
2. Remove wiring plug from back of lamp.
3. Install new lamp by reconnecting wiring plug to new lamp and pushing lamp into
rubber grommet until properly seated.
* Apply a small amount of soapy water to grommet for ease of installation.
Clearance Marker and ICC Light Replacement:
1. From inside, unplug the lamp, push lamp out of the grommet. To replace, from the
outside push the lamp into grommet. Some lubrication helps installation. Install so
the marking is towards the top. Hook up wiring taking care to match the polarity.
LAMPS
