2019 Amazon P80 Package Delivery Vehicle
Side Door Installation:
1. Tilt the top of the door in place rst. Now position the bottom of the door into the
lower door track, which is in position but not fastened down.
2. Put 1/8” shims between the lower door track and the wear strip.
3. Mount door to the hanger assembly.
4. Install door handles. See page 6.
5. Mount grab handle forward of door. *Return mirror to previous position.
6. For proper door adjustment see page 8.
Door Track and Hanger Plate removal without door removal.
1. Remove access cover located on upper rear corner of the door pocket.
2. Remove the the door hanger nuts and bolts, slide the door hanger plate to the rear
of the door pocket and remove.
3. Remove the door track nuts, lower the track away from the header channel and
slide towards the rear and out throught the access area.
4. Re-install in reverse order and follow the door installation, steps 2 and 3, and ad-
justment steps.
