freightliner Sprinter Owner's Manual

No. Relays Description
R14 K13/7 Windshield heating relay 1
R15 K88 Body manufacturer relay, terminal 15
R16 K88/1 Body manufacturer relay, terminal 61 (D+)
R17 K95
K93
K122
Loading tailgate relay
Comfort illumination relay
LED light strip relay, passengercompartment
lighting
R18 K2 Headlamp cleaning system relay
R19 K51/10
K118
Beacon with siren relay
Entrance lighting relay (bus)
R20 K39/3 ATA (anti-theft alarm system) relay, horn
R21 K108
K116
K23/2
Perimeter lamp relay
License plate lamp relay (courier vehicles)
Blower relay, hot-air auxiliary heating, blower setting
1
R22 K23/3 Blower relay, hot-air auxiliary heating, blower setting
2
R23 K39/1
K124/1
Siren relay
Terminal 61 (D+) relay, anti-theft protection with
vehicle tracking
R24 K117/1 Electrical step relay 1, sliding door, right/co-driver's
door (bus)
R25 K117/2 Electrical step relay 2, sliding door, right/co-driver's
door (bus)
R26 K121
K124
Reverse warning device off relay
Anti-theft protection with vehicle tracking relay
Other relays
No. Relays Description
— K57 Battery cutoff relay
— K57/4 Auxiliary battery relay, right-hand-drive vehicle
— K9 Air-conditioning system relay, auxiliary fan (duo)
