• Like the adaptor plates, the inlet guides are not
identical. One is for the top and one is for the
bottom.
• Like the adaptor plates, the inlet guides must be
at least 0.2 mm larger than the fiber. Example: If
the fiber is 1.1 mm, choose
1.3 mm inlet guides.
• Click the inlet guides into position at top and
bottom.
• The machine is now ready for use.
