RWF ROTARY SCREW COMPRESSOR UNITS
MAINTENANCE
S70-600 IOM
Page 49
START-UP REPORT
Sold To: _____________________________________ Contact Name: ______________________ Date: _______________
End User: ___________________________________ Contact Name: ______________________ Phone: ______________
End User Address: _________________________________________________________________ Fax No: _____________
City, State, Zip: ________________________________________________ Start-up Rep. _____________________________
Unit General Information
Unit Model # _______________________________ Customer Package Identification #_____________________________
Compressor Serial # ________________________ Separator National Board # __________________________________
Unit Serial # _______________________________ Oil Cooler National Board # __________________________________
Refrigerant
R-717 R-22 R-290 Other ___________________
Lube Oil Type
2A 3 4 9 Other _______ Design Operating Conditions
Lube System
None Prelube Cycling Full Demand ______ °Suct./ _____ °Disch.
Oil Cooling
TSOC WCOC S-LIOC D-LIOC GCOC
Oil Filters
Single Dual Micro Log I.D. ____________________
Micro Information
Micro Type Quantum Plus Standard Electromechanical U3, U4, U5 Program ___________
SBC / CPU Serial # _________ Rev. ___ U24/U35 Program ID/OS Ver # ____________ and Date ____________
U36 Bios Ver # ______ and Date __________ U42 Keyboard Ver #_________________ and Date ____________
Digital I/O Board #1 Serial #_____________ Rev. _______ U8 Digital I/O Ver # ____________ and Date _________
Digital I/O Board #2 Serial #_____________ Rev. _______ U8 Digital I/O Ver # ____________ and Date _________
Analog Board #1 Serial # _____________ Rev. _____ U13 Analog Ver #_________ and Date ______________
Analog Board #2 Serial # _____________ Rev. _____ U13 Analog Ver #_________ and Date ______________
Compressor Motor Information
Manufacturer _________________________________ Frame Size _____________ H.P. ___________ RPM _________
Serial # ___________________________Service Factor ______________Voltage __________ Hz _______ FLA _________
Design __________ Code ______________ Bearing Type Antifriction Sleeve
Compressor Motor Starter Information
Manufacturer __________________________ Serial # ___________________________
Starter Type
WDCT ATL Auto-Trans Solid State Digital DBS Standalone DBS
CT Location Checked CT Phase _____ CT Ratio ______ Transition Time ___________ DBS Ver. # ____________
Oil Pump Information
Pump Manufacturer _________________ Model # ____________________ Serial # ________________________
Motor Manufacturer _________________ H.P. _________ RPM ________ Serial # ________________________
Service Factor ______ Voltage ______ Hz __________ FLA ________ Design ______ Code ____ Starter Size ____
Special Options
DX Economizer Frick Supplied Starter PC Control System Other
Prestart Checks
Position of all valves All wiring connections Motor rotation Oil pump motor rotation
All micro settings Cold alignment Proper oil charge Installation, Foundation
Factory Setup Options (Quantum™)
RWB II RWF RXF RDB 3-Step RDB 4-Step Other GSV II GST GSF GSB
No Pump Prelube Cycling Full Time Dual Oil Filter Transducer Yes No
Refrigerant __________ K-Factor for User Defined Refrigerant________ Slide Valve Travel ____________
Dual Dischaarge Control
Enabled Disabled Liquid Injection Cooling Enabled Disabled
Main Oil Injection Control
Enabled Disabled Balance Piston Setup Enabled Disabled
Oil Log Setup
Enabled Disabled Enable Aux 1 & 2 None 1 2 Both
To Next Page
