SGC/SGX ROTARY SCREW COMPRESSOR
INSTALLATION
Installation
DESIGN LIMITS
Information for all of the models is provided below. See
CoolWare to determine the limits for a specic application.
SGC/SGX compressor models are primarily designed to con-
nect to an electric drive motor using a tunnel mount. If the
application requires, the compressor can also be driven with
a foot-mounted motor. The tunnel mount ensures proper
alignment of the compressor and motor so that the shaft seal
and coupling operate properly. The rotor and bearing design
set limitations must not be exceeded (Refer to CoolWare).
Refer to 090.020-M - FRICK Compressor Control Panel for
additional information on set-point limits.
For proper piping, also refer to the FRICK package manual,
070.610-IOM - RWF II Rotary Screw Compressor Units,
Models 100 through 1080.
OUTLINE DIMENSIONS
Drawings, for reference only, can be found in Figure 3 to
Figure 9. Complete dimensions and access connections
can be found on the outline drawings.
 SGC1913and1918  DWG#534E0677
 SGC2313and2317  DWG#534E0700
 SGC2321   DWG#534E0714
 SGC2813and2817  DWG#534E0749
 SGC2821   DWG#534E0768
 SGC2824   DWG#534E0973
 SGCH3511andSGCB3511 DWG#534E0966
 SGCH3515andSGCB3515 DWG#534E0971
 SGCH3519andSGCB3519 DWG#534E0972
 SGXH3519andSGXB3519/3524 DWG#534E1405
 SGXH4013,4018,and4021 DWG#534E1403
If you do not have these drawings, request any you require
by contacting Johnson Controls - FRICK sales.
