10.Lay the refrigerator on soft foam packaging or similar material. Remove both
adjustable bottom feet parts, and remove the front feet board and the lower
hinge part by unscrewing the special flange self-tapping screws.
1 Lower hinge part (right)
2 Adjustable bottom feet part
3 Self tapping screws
12 Replace the lower hinge part to the left side and fixing it with the special
flange self-tapping screws. Replace the front feet fixed board to another side
and fixing it with the special flange self-tapping screws. Install the adjustable
bottom feet parts.
13.Transfer the lower door to the property position, adjust the lower hinge part,
make the hinge axis into the lower hole of the lower door, then tight the bolts.
14.Upturn the middle hinge part the direction 180 degree, transfer it and adjust
its position, make the middle hinge axis into the upper hole of the lower door,
tight the bolts.
middle hinge part
self-tapping screw
