51 PB
PARTS CATALOG
Chill Premier Models: CCW06B10A CCW08B10A CCW10B10A CCW12B10A
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
6 68000211 41509-000049 - Adjustable shade CCW06B10A, CCW08B10A, CCW10B10A, CCW12B10A 1
7 68000221 41509-000053 - left Adjustable
shade rail
CCW06B10A, CCW08B10A, CCW10B10A, CCW12B10A 1
8 68000222 41508-000016_UI - Cabinet CCW06B10A, CCW08B10A, CCW10B10A, CCW12B10A 1
9 68000223 41509-000023 - Up Adjustable
shade rail
CCW06B10A, CCW08B10A, CCW10B10A, CCW12B10A 1
10 68000224 41509-000051 - Right Adjustable
shade rail
CCW06B10A, CCW08B10A, CCW10B10A, CCW12B10A 1
11 68000205 92011-005038 - Condenser CCW06B10A, CCW08B10A, CCW10B10A 1
11A 68000260 92011-005088 - Condenser CCW10B10A 1
11B 68000268 92011-004641 - Condenser CCW12B10A 1
12 68000225 41503-000007_UI - Propeller Fan CCW06B10A, CCW08B10A, CCW10B10A, CCW12B10A 1
13 68000226 41504-000192_UI - Back
Surround Plate
CCW06B10A, CCW12B10A 1
13A 68000250 41504-000193 - Back Surround
Plate
CCW08B10A, CCW10B10A 1
14 68000227 22001-000427_UI - Fan Motor CCW06B10A, CCW08B10A 1
14A 68000261 22001-000394 - Fan Motor CCW10B10A, CCW12B10A 1
15 68000228 41503-000010_UI - Centrifugal
Fan
CCW06B10A, CCW08B10A, CCW10B10A, CCW12B10A 1
16 68000229 41504-000173_UI - Water
drainage pan
CCW06B10A, CCW08B10A, CCW10B10A, CCW12B10A 1
17 68000230 92014-000599 - Compressor CCW06B10A 1
17A 68000254 92014-000259 - Compressor CCW08B10A 1
17B 68000262 92014-000305 - Compressor CCW10B10A 1
17C 68000270 92014-000262 - Compressor CCW12B10A 1
18 68000231 41502-000042 - Base CCW06B10A, CCW08B10A, CCW10B10A, CCW12B10A 1
-19 68000232 10104-100026 - Sensor CCW06B10A, CCW08B10A, CCW10B10A, CCW12B10A 1
-20 68000233 31502-000025 - Display PCB CCW06B10A, CCW08B10A, CCW10B10A, CCW12B10A 1
-24 68000237 32001-000129 - WIFI Assembly CCW06B10A, CCW08B10A, CCW10B10A, CCW12B10A 1
1-ITEMS ARE NON- ILLUSTRATED
*1ITEMS ARE NON-STOCKED, WILL NORMALLY REQUIRE 2-3 WEEKS LEAD TIME
FIgure 901
To Next Page
