53 PB
PARTS CATALOG
Chill Premier Models: CCW15B10A CCW18B30A
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
21 68000301 41214-000856 - Pipe Cover (two-way) CCW15B10A, CCW18B30A 1
22 68000302 41602-000016_UW - Base CCW15B10A, CCW18B30A 1
23 68000303 92014-000260 - Compressor CCW15B10A 1
23A 68000321 92014-000275 - Compressor CCW18B30A 1
24 68000304 22007-000280_UW - Compressor wire CCW15B10A, CCW18B30A 1
25 68000257 42001-000057 - Cable Clamp CCW15B10A, CCW18B30A 1
25A 68000322 42001-000058 - Cable Clamp CCW15B10A, CCW18B30A 1
26 68000305 41605-000011 - Sensor Holder CCW15B10A, CCW18B30A 1
27 68000306 92011-003343 - Evaporator CCW15B10A 1
27A 68000323 92011-003349 - Evaporator CCW18B30A 1
27.1 68000307 92007-001542 - Capillary Assembly CCW15B10A 1
27.1A 68000324 92007-001525 - Capillary Assembly CCW18B30A 1
27.2 68000308 92006-000181 - Discharge Pipe CCW15B10A 1
27.2A 68000325 92006-000180 - Discharge Pipe CCW18B30A 1
28 68000309 41505-000233 - Electrical Box CCW15B10A, CCW18B30A 1
28.1 68000310 41214-000877_UW - Main pcb supporter CCW15B10A, CCW18B30A 1
28.2 68000311 11201-100000 - Main pcb CCW15B10A 1
28.2A 68000326 31502-000006_UW - Main pcb CCW18B30A 1
28.3 68000312 10303-100043_UW - Capacitor CCW15B10A 1
28.3A 68000327 10303-100040_UW - Capacitor CCW18B30A 1
28.4 68000313 10502-100032_UW - Transformer CCW15B10A 1
28.4A 68000328 10502-100034_UW - Transformer CCW18B30A 1
28.5 68000189 42001-000027 - Capacitor Strip CCW15B10A 1
28.5A 68000329 42001-000025 - Capacitor Strip CCW18B30A 1
-29 68000314 22013-000936 - Remote Controller CCW15B10A, CCW18B30A 1
-30 68000179 41507-000031 - Control Box panel CCW15B10A, CCW18B30A 1
-31 68000315 31502-000027 - Display PCB CCW15B10A, CCW18B30A 1
-35 68000319 22007-000069_UW - Power Supply Cord CCW15B10A 1
-35A 68000331 22007-000067_UW - Power Supply Cord CCW18B30A 1
-36 68000237 32001-000129 - WIFI Assembly CCW15B10A, CCW18B30A 1
-ITEMS ARE NON- ILLUSTRATED
*ITEMS ARE NON-STOCKED, WILL NORMALLY REQUIRE 2-3 WEEKS LEAD TIME
FIgure 902
To Next Page
