62 PB
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
9 68000377 210755615A - Display PCB cover UCT08A10A, UCT10A10A, UCT12A10A, UCT10A30A 1
10 68000132 210738277 - Control Box panel UCT08A10A, UCT10A10A, UCT12A10A, UCT10A30A 1
11 68000378 210836910 - Electrical Box UCT08A10A, UCT10A10A, UCT12A10A, UCT10A30A 1
12 68000040 210901721 - Transformer UCT08A10A, UCT10A10A, UCT12A10A 1
12A 68000062 210901700 - Transformer UCT10A30A 1
13 68000041 210901745 - Fan Motor Capacitor UCT08A10A, UCT10A10A, UCT12A10A, UCT10A30A 1
14 68000379 210836752 - Electrical Box Cover UCT08A10A, UCT10A10A, UCT12A10A, UCT10A30A 1
15 68000030 210901411P - Main pcb UCT08A10A, UCT10A10A, UCT12A10A, UCT10A30A 1
16 68000065 210736568 - Main pcb supporter UCT08A10A, UCT10A10A, UCT12A10A, UCT10A30A 1
17 68000380 210738282 - Capacitor Strip UCT08A10A, UCT10A10A, UCT12A10A, UCT10A30A 1
18 68000043 1170100033A - Compressor
Capacitor
UCT08A10A 1
18A 68000000 1170100007C - Compressor
Capacitor
UCT10A10A 1
18B 68000047 1170100023A - Compressor
Capacitor
UCT10A30A 1
18C 68000001 210901831 - Compressor
Capacitor
UCT12A10A 1
19 68000006 210738336 - Centrifugal Fan UCT08A10A, UCT10A10A, UCT12A10A, UCT10A30A 1
20 68000381 210738267A - foam shell UCT08A10A, UCT10A10A, UCT12A10A, UCT10A30A 1
21 68000382 210836909A - Partition plate UCT08A10A, UCT10A10A, UCT12A10A, UCT10A30A 1
22 68000383 211237425 - Compressor UCT08A10A 1
22A 68000393 211236834 - Compressor UCT10A10A 1
22B 68000396 211231767 - Compressor UCT10A30A 1
22C 68000400 211238084 - Compressor UCT12A10A 1
23 68000044 210901757 - Fan Motor UCT08A10A, UCT10A10A 1
23A 68000068 210901723 - Fan Motor UCT10A30A 1
23B 68000002 210901722 - Fan Motor UCT12A10A 1
24 68000384 211237435 - Discharge Pipe UCT08A10A 1
24A 68000394 211238696 - Discharge Pipe UCT10A10A 1
24B 68000394 211238696 - Discharge Pipe UCT10A30A 1
24C 68000401 211236902 - Discharge Pipe UCT12A10A 1
25 68000069 210738266A - Back Partition plate UCT08A10A, UCT10A10A, UCT12A10A, UCT10A30A 1
26 68000070 210738337 - Propeller Fan UCT08A10A, UCT10A10A, UCT12A10A, UCT10A30A 1
27 68000385 211236831B - Condenser UCT08A10A, UCT10A10A, UCT12A10A, UCT10A30A 1
27A 68000402 211236922B - Condenser UCT12A10A 1
28 68000071 210836745 - Cabinet UCT08A10A, UCT10A10A, UCT12A10A, UCT10A30A 1
29 68000072 210836793 - grille UCT08A10A, UCT10A10A, UCT12A10A, UCT10A30A 1
PARTS CATALOG
Unit Models: UCT08A10A UCT10A10A UCT12A10A UCT10A30A
