PARTS CATALOG
Unit Models: UET08A11A UET10A33A UET12A33A
FIgure 908
12 68000040 210901721 - Transformer UET08A11A 1
12A 68000062 210901700 - Transformer UET10A33A, UET12A33A 1
13 68000041 210901745 - Fan Motor Capacitor UET08A11A 1
13A 68000046 1170100030A - Fan Motor
Capacitor
UET10A33A 1
13B 68000063 1170100034A - Fan Motor
Capacitor
UET12A33A 1
14 68000379 210836752 - Electrical Box Cover UET08A11A, UET10A33A, UET12A33A 1
15 68000042 210901411S - Main pcb UET08A11A 1
15A 68000064 210901411R - Main pcb UET10A33A, UET12A33A 1
16 68000065 210736568 - Main pcb supporter UET08A11A, UET10A33A, UET12A33A 1
17 68000380 210738282 - Capacitor Strip UET08A11A, UET10A33A, UET12A33A 1
18 68000043 1170100033A - Compressor
Capacitor
UET08A11A 1
18A 68000047 1170100023A - Compressor
Capacitor
UET10A33A 1
18B 68000066 1170100004A - Compressor
Capacitor
UET12A33A 1
19 68000067 210738381 - Centrifugal Fan UET08A11A, UET10A33A, UET12A33A 1
20 68000411 210738267 - foam shell UET08A11A, UET10A33A, UET12A33A 1
21 68000382 210836909A - Partition plate UET08A11A, UET10A33A, UET12A33A 1
22 68000383 211237425 - Compressor UET08A11A 1
22A 68000396 211231767 - Compressor UET10A33A 1
22B 68000403 211238076 - Compressor UET12A33A 1
23 68000044 210901757 - Fan Motor UET08A11A 1
23A 68000068 210901723 - Fan Motor UET10A33A, UET12A33A 1
24 68000384 211237435 - Discharge Pipe UET08A11A 1
24A 68000394 211238696 - Discharge Pipe UET10A33A 1
24B 68000401 211236902 - Discharge Pipe UET12A33A 1
25 68000069 210738266A - Back Partition plate UET08A11A, UET10A33A, UET12A33A 1
26 68000070 210738337 - Propeller Fan UET08A11A, UET10A33A, UET12A33A 1
27 68000385 211236831B - Condenser UET08A11A, UET10A33A 1
27A 68000402 211236922B - Condenser UET12A33A 1
28 68000071 210836745 - Cabinet UET08A11A, UET10A33A, UET12A33A 1
29 68000072 210836793 - grille UET08A11A, UET10A33A, UET12A33A 1
30 68000048 210836767 - intake and outtake
grille
UET08A11A, UET10A33A, UET12A33A 1
31 68000412 210836781 - Base UET08A11A, UET10A33A, UET12A33A 1
32 68000050 210901012 - Drainage valve UET08A11A, UET10A33A, UET12A33A 1
33 68000051 210738265 - Water drainage pan UET08A11A, UET10A33A, UET12A33A 1
