239 PB
COMPONENTS TESTING
24k Outdoor Drive Printed Circuit Board
NO. Description NO. Description
1 IGBT 7 15V & 5V Power
2 8 Diodes MCU
3 9 Rectifier Bridge CPU Code
4 10Drive Board Code
5
Communication with Upper System
AC Power Input 11 IPM Module
6 EE
