319 PB
PARTS CATALOG
18K Indoor Cassette
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
1 67400872 Base FPHC18A3A, FPHC18A3B 1
2 67400984 Air Duct Plate FPHC18A3A, FPHC18A3B 1
3 67400438 Fan Motor FPHC18A3A, FPHC18A3B 1
4 67400985 Side Panel FPHC18A3A, FPHC18A3B 1
5 67400986 Fan Snail Shell FPHC18A3A, FPHC18A3B 1
6 67400439 Pump Motor FPHC18A3A, FPHC18A3B 1
7 67400987 Cover FPHC18A3A, FPHC18A3B 1
8 67400440 Drainage Hose FPHC18A3A, FPHC18A3B 1
9 67400441 Centrifugal Fan FPHC18A3A, FPHC18A3B 1
10 67400442 Water Collecting Box FPHC18A3A, FPHC18A3B 1
11 67400988 Mounting Plate FPHC18A3A, FPHC18A3B 1
12 67400865 Elec Joint Box FPHC18A3A, FPHC18A3B 1
13 67400989 Elec Joint Box Cover FPHC18A3A, FPHC18A3B 1
14 67400365 Terminal Panel FPHC18A3A, FPHC18A3B 1
15 67400436 Main Control Board FPHC18A3A, FPHC18A3B 1
16 67400990 Cross Recessed Cheese Head
Screws
FPHC18A3A, FPHC18A3B 1
17 67400444 Coil Temperature Sensor FPHC18A3A, FPHC18A3B 1
18 67400991 Mounting Plate FPHC18A3A, FPHC18A3B 1
19 67400437 Evaporator FPHC18A3A, FPHC18A3B 1
20 67400992 Side Panel FPHC18A3A, FPHC18A3B 1
21 67400993 Connecting Plate FPHC18A3A, FPHC18A3B 1
22 67400994 Side Panel FPHC18A3A, FPHC18A3B 1
23 67400446 Ambient Temperature Sensor FPHC18A3A, FPHC18A3B 1
24 67400447 Water Level Switch FPHC18A3A, FPHC18A3B 1
-25 67401169 WIFI module FPHC18A3B 1
-ITEMS ARE NON- ILLUSTRATED
*ITEMS ARE NON-STOCKED, WILL NORMALLY REQUIRE EXTENDED LEAD TIME
FIgure 907
