308 PB
PARTS CATALOG
36K Outdoor Condensor
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
37 67400401 Noise-Insulation Cotton FPHMR36A3A 1
38 67400946 supporting component FPHMR36A3A 1
39 67400922 xed board FPHMR36A3A 1
40 67400402 Tube type electric heater FPHMR36A3A 1
41 67400361 Pressure Switch FPHMR36A3A 1
42 67400362 Pressure Switch FPHMR36A3A 1
43 67400403 Outdoor Main Control Board
Component
FPHMR36A3A 1
44 67400404 Filter board FPHMR36A3A 1
45 67400948 Mounting Plate Essy FPHMR36A3A 1
46 67401009 Connecting Plate FPHMR36A3A 1
47 67400405 AC Contactor FPHMR36A3A 1
48 67401010 Compressor Mounting Plate
Parts
FPHMR36A3A 1
49 67400406 Radiator FPHMR36A3A 1
50 67400951 Mounting Plate FPHMR36A3A 1
51 67400407 driver board FPHMR36A3A 1
52 67400364 Wire Terminal Board FPHMR36A3A 1
53 67400365 Wire Terminal Board FPHMR36A3A 1
54 67400408 Temperature Sensor FPHMR36A3A 1
55 67400367 Temperature Sensor FPHMR36A3A 1
56 67400368 Temperature Sensor FPHMR36A3A 1
-ITEMS ARE NON- ILLUSTRATED
*ITEMS ARE NON‑STOCKED, WILL NORMALLY REQUIRE EXTENDED LEAD TIME
FIGURE 903
To Next Page
