Friedrich FPHFW09A3A User Manual

105 PB
PARTS CATALOG
230V Outdoor Unit 18k
Figure 910
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
18 67400272 1844583 ‑ 1/4 2‑way valve FPHSR18A3A 1
19 67400299 1844499 ‑ 1/2 3‑way valve FPHSR18A3A 1
20 67400803 1841776 ‑ right side board FPHSR18A3A 1
21 67400201 1854040 ‑ wiring distribution
cover assy
FPHSR18A3A 1
22 67400202 1854034 ‑ xed board FPHSR18A3A 1
23 67400203 1842392 ‑ connecting board FPHSR18A3A 1
24 67400204 1852124 ‑ Wire terminal board FPHSR18A3A 1
25 67400205 1841985 ‑ electric box FPHSR18A3A 1
26 67400300 1854367 ‑ Controller Component FPHSR18A3A 1
27 67400207 1546706 ‑ electric box cover FPHSR18A3A 1
28 67400301 1511780 ‑ Temperature sensor FPHSR18A3A 1
29 67400302 1511782 ‑ Temperature sensor FPHSR18A3A 1
30 67400210 1831029 ‑ Temperature sensor FPHSR18A3A 1
31 67400809 1982183 ‑ sensor mounting plate FPHSR18A3A 1
‑ITEMS ARE NON‑ ILLUSTRATED
*ITEMS ARE NON‑STOCKED, WILL NORMALLY REQUIRE EXTENDED LEAD TIME
