PARTS CATALOG
230V Indoor Unit 9-12K
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
21 67400588 4113865 ‑ panel FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
22 67400589 1964953 ‑ Motor bracket FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
23 67400590 1964954 ‑ motor cover FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
24 67400591 1964950 ‑ center staff FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
25 67400592 1964956 ‑ motor cover FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
26 67400174 1260259 ‑ Step motor FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
27 67400550 1964955 ‑ Motor bracket FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
28 67400595 1467336 ‑ Step motor FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
29 67400596 1964945 ‑ ornamental part FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
30 67400485 1964949 ‑ bafe FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
31 67400598 1964939 ‑ axes FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
32 67400599 1964940 ‑ wiring distribution
cover assy
FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
33 67400600 1964938 ‑ decorative panel FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
34 67400487 1978713 ‑ Water pipe parts FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
35 67400602 1964936 ‑ Motor hoop FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
36 67400331 1838324 ‑ DC motor FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
37 67400603 1964934 ‑ motor guard FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
38 67400604 1961612 ‑ electric box cover FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
39 67400489 1961613 ‑ button FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
40 67400490 1988669 ‑ Power Switch FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
41 67400559 1988777 ‑ Jiggle switch FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
42 67400786 1959674 ‑ electric box FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
43 67400609 1961611 ‑ electric box FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
44 67400330 2010509 ‑ Indoor Main Control
Board Component
FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
45 67400166 1852126 ‑ Wire terminal board FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
46 67400611 1959675 ‑ guard cover FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
47 67400612 2010238 ‑ guard cover FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
48 67400161 4084109 ‑ Remote Controller FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
49 67400494 1831400 ‑ Temperature sensor FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
50 67400495 1965628 ‑ Temperature sensor FPHFW09A3A, FPHFW09A3B, FPHFW12A3A, FPHFW12A3B 1
‑51 67401169 WIFI module FPHFW09A3B, FPHFW12A3B 1
‑ITEMS ARE NON‑ ILLUSTRATED
*ITEMS ARE NON‑STOCKED, WILL NORMALLY REQUIRE EXTENDED LEAD TIME
Figure 902
