Friedrich FPHFW09A3A User Manual

95 PB
PARTS CATALOG
230V Indoor Unit 18K
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
22 67400481 Display kit FPHFW18A3A, FPHFW18A3B 1
23 67400482 Front Panel FPHFW18A3A, FPHFW18A3B 1
28 67400174 Stepper Motor FPHFW18A3A, FPHFW18A3B 1
30 67400222 Stepper motor harness FPHFW18A3A, FPHFW18A3B 1
31 67400485 bafe FPHFW18A3A, FPHFW18A3B 1
32 67400598 Louver Pins FPHFW18A3A, FPHFW18A3B 1
34 67400487 Drain Pipe FPHFW18A3A, FPHFW18A3B 2
36 67400488 Blower Motor FPHFW18A3A, FPHFW18A3B 1
39 67400489 ELEC Panel Switch FPHFW18A3A, FPHFW18A3B 1
40 67400490 Front Cover Switch FPHFW18A3A, FPHFW18A3B 1
44 67400491 Indoor Main Control Board FPHFW18A3A, FPHFW18A3B 1
46 67400492 Terminal Block FPHFW18A3A, FPHFW18A3B 1
49 67400611 guard cover FPHFW18A3A, FPHFW18A3B 1
50 67400494 Upper Thermistor FPHFW18A3A, FPHFW18A3B 1
51 67400495 Lower Thermistor FPHFW18A3A, FPHFW18A3B 1
52 67400496 Remote Control FPHFW18A3A, FPHFW18A3B 1
‑53 67401169 WIFI module FPHFW18A3B 1
‑ITEMS ARE NON‑ ILLUSTRATED
*ITEMS ARE NON‑STOCKED, WILL NORMALLY REQUIRE EXTENDED LEAD TIME
Figure 905

Friedrich FPHFW09A3A Specifications

General

Brand	Friedrich
Model	FPHFW09A3A
Category	Air Conditioner
Language	English
