PARTS CATALOG
230V Indoor Unit 36k
ITEM PART NUMBER PART DESCRIPTION USED ON MODEL QTY
17 67400628 1531621 ‑ center staff FPHSW36A3A, FPHSW36A3B, FPHSW36A3C 1
18 67400629 1531638 ‑ center staff FPHSW36A3A, FPHSW36A3B, FPHSW36A3C 1
19 67400630 1550405 ‑ Step motor FPHSW36A3A, FPHSW36A3B, FPHSW36A3C 1
20 67400631 1510271 ‑ motor guard FPHSW36A3A, FPHSW36A3B 1
20 67400639 motor guard FPHSW36A3C 1
21 67400632 1550959 ‑ center staff FPHSW36A3A, FPHSW36A3B, FPHSW36A3C 1
22 67400633 1508995 ‑ level vane FPHSW36A3A, FPHSW36A3B, FPHSW36A3C 1
23 67400634 1508996 ‑ level vane FPHSW36A3A, FPHSW36A3B, FPHSW36A3C 1
24 67400635 1510138 ‑ shell FPHSW36A3A, FPHSW36A3B 1
24 67401200 shell FPHSW36A3C 1
25 67400636 1510158 ‑ mounting plate FPHSW36A3A, FPHSW36A3B, FPHSW36A3C 1
26 67400319 1856546 ‑ Display Component FPHSW36A3A, FPHSW36A3B 1
26 67401201 display assembly FPHSW36A3C 1
27 67400637 4113867 ‑ panel FPHSW36A3A, FPHSW36A3B, FPHSW36A3C 1
28 67400638 1900480 ‑ Refrigeration system FPHSW36A3A, FPHSW36A3B 1
28 67401253 Refrigeration system FPHSW36A3C 1
29 67400639 1531644 ‑ motor guard FPHSW36A3A, FPHSW36A3B, FPHSW36A3C 1
30 67400320 1837643 ‑ DC motor FPHSW36A3A, FPHSW36A3B, FPHSW36A3C 1
31 67400161 4084109 ‑ Remote Controller FPHSW36A3A, FPHSW36A3B, FPHSW36A3C 1
32 67400235 1383891 ‑ Temperature sensor FPHSW36A3A, FPHSW36A3B, FPHSW36A3C 1
33 67400323 1473879 ‑ Temperature sensor FPHSW36A3A, FPHSW36A3B, FPHSW36A3C 1
34 67400640 1510281 ‑ wiring distribution
cover assy
FPHSW36A3A, FPHSW36A3B, FPHSW36A3C 1
35 67400641 1510280 ‑ electric box cover FPHSW36A3A, FPHSW36A3B, FPHSW36A3C 1
36 67400166 1852126 ‑ Wire terminal board FPHSW36A3A, FPHSW36A3B, FPHSW36A3C 1
37 67400643 1868943 ‑ electric box FPHSW36A3A, FPHSW36A3B, FPHSW36A3C 1
38 67400324 1918102 ‑ Indoor Main Control
Board Component
FPHSW36A3A, FPHSW36A3B 1
38 67401254 indoor electrical control board
ASS'Y
FPHSW36A3C 1
39 67400644 1510284 ‑ elec joint box plate FPHSW36A3A, FPHSW36A3B 1
39 67400645 electric box plate FPHSW36A3C 1
40 67400645 1510290 ‑ elec joint box plate FPHSW36A3A, FPHSW36A3B 1
40 67400644 electric box plate FPHSW36A3C
41 67400646 1509002 ‑ bafe FPHSW36A3A, FPHSW36A3B, FPHSW36A3C 1
‑42 67400257 1510154 ‑ Filter net FPHSW36A3A, FPHSW36A3B, FPHSW36A3C 1
‑43 67401169 WIFI module FPHSW36A3B, FPHSW36A3C 1
‑ITEMS ARE NON‑ ILLUSTRATED
*ITEMS ARE NON‑STOCKED, WILL NORMALLY REQUIRE EXTENDED LEAD TIME
Figure 907
