214 PB
PARTS CATALOG
24K Outdoor Condensor
FIGURE 902
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
38 67400932 discharge tube assy FPHMR24A3A 1
39 67400369 4‑way valve assembly FPHMR24A3A 1
40 67400933 mounting plate FPHMR24A3A 1
41 67400370 Driver board FPHMR24A3A 1
42 67400371 Outdoor Main Control Board
Component
FPHMR24A3A 1
43 67400372 Filter board FPHMR24A3A 1
44 67400934 elec joint box assy FPHMR24A3A 1
45 67400373 Aluminum electrolytic capacitor FPHMR24A3A 1
46 67400374 radiator FPHMR24A3A 1
47 67400365 Connect terminal panel FPHMR24A3A 1
48 67400364 Power terminal panel FPHMR24A3A 1
49 67401005 clamp FPHMR24A3A 1
50 67401006 clamp FPHMR24A3A 1
51 67400377 TEMPERATURE SENSOR FPHMR24A3A 1
52 67400378 TEMPERATURE SENSOR FPHMR24A3A 1
53 67400379 TEMPERATURE SENSOR FPHMR24A3A 1
‑54 67400393 Reversing valve FPHMR24A3A 1
‑‑ITEMS ARE NON‑ ILLUSTRATED
*ITEMS ARE NON‑STOCKED, WILL NORMALLY REQUIRE 2‑3 WEEKS LEAD TIME
