PARTS CATALOG

24k Ducted Indoor

Figure 909

ITEM PART

NUMBER

PART DESCRIPTION USED ON MODEL QTY

1 67400952 Base Plate FPHD24A3A 1

2 67400953 Base Holder FPHD24A3A 1

3 67400954 Water Drain FPHD24A3A 1

4 67400955 Rubber Plug FPHD24A3A 1

5 67400956 Evaporator assembly FPHD24A3A 1

6 67400957 Supporting FPHD24A3A 1

7 67400958 Outlet Flange Border FPHD24A3A 1

8 67400959 Supporting FPHD24A3A 1

9 67400960 Supporting FPHD24A3A 1

10 67400961 Tie‑in FPHD24A3A 1

11 67400962 Water Pipe FPHD24A3A 1

12 67400433 Pump Motor FPHD24A3A 1

13 67400963 Electric Box Cover FPHD24A3A 1

14 67400964 Inlet Flange Border FPHD24A3A 1

15 67400965 Float Bracket FPHD24A3A 1

16 67400447 Water Position Switch FPHD24A3A 1

17 67400444 Coil Temperature Sensor FPHD24A3A 1

18 67400255 Ambient Temperature Sensor FPHD24A3A 1

19 67400966 Supporting FPHD24A3A 1

20 67400967 Motor Bracket FPHD24A3A 1

21 67400968 Centrifugal Fan Blade FPHD24A3A 1

22 67400969 Center Staff FPHD24A3A 1

23 67400970 Motor Hoop FPHD24A3A 1

24 67400971 Motor Hoop FPHD24A3A 1

25 67400972 DC Motor FPHD24A3A 1

26 67400973 Fan Snail Shell FPHD24A3A 1

27 67400974 Electric Box FPHD24A3A 1

28 67400429 Supporting Leg FPHD24A3A 1

29 67400365 Wire Terminal Board FPHD24A3A 1

30 67400975 Main Control Board FPHD24A3A 1

‑31 67400997 Wire control components FPHD24A3A 1

‑ITEMS ARE NON‑ ILLUSTRATED

*ITEMS ARE NON‑STOCKED, WILL NORMALLY REQUIRE 2‑3 WEEKS LEAD TIME
