27 PB
INSTALLATION
Capacity
(Btu/h)
Pipe Size Standard
Length (ft)
Max.
Elevation
B (ft)
Max. Length
A (ft)
Additional
Refrigerant
(oz/ft)
LIQUID GAS
9k-12 1/4"(Ø6.35) 3/8"(Ø9.52) 25 33 50 .22
18k 1/4"(Ø6.35) 1/2"(Ø12.7) 25 33 66 .22
24k-36k 3/8"(Ø9.52) 5/8"(Ø15.88) 25 33 66 .32
5
Figure 403
Figure 404
