40 PB
FRONT FRAME WITH
MESH FILTER
ALIGN HOLES WITH
PROTRUSION
ROUTINE MAINTENANCE
Premium Carbon Filter Removal / Installation Instructions
Figure 405
1. Remove the lter per Standard Filter Removal Installation Refer to Figure 402 and 403.
2. Hold the lter at the top and slide the grip out as shown on Figure 405.
3. If you already have a carbon lter installed remove the dirty lter by laying the lter down and swinging open the front
frame as shown in Figure 406.
NOTE: Make sure the frame with the mesh is facing toward you.
4. Place the new carbon lter on the top of the back lter frame. The carbon lter has been cut to the correct dimension
and should t within the frame as shown in Figure 406.
NOTE: The carbon lter is not a reusable lter, and needs to be replaced every three months for optimum efciency.
5. Slide the lter handle back on to hold the frames together and slide the assembly into the unit as per the instructions
on the door.
NOTE: The lter handle slides into the frame in only one direction. If the tab in the frame stops the handle from sliding in, slide
the handle from the other direction. DO NOT FORCE THE HANDLE INTO THE FRAME.
Figure 406
