6.2 The Product doesn't operate with the remote controller
Turn on the main power
Yes
No
A "Beeping" sound is made
from the indoor unit
* Refer to 10.1
*
Check the voltage of power
(AC208V/AC230V, 60Hz).
Is it possible to turn on the unit
by ON/OFF button on display?
Yes
No
Is the remote controller
working properly?
Yes
* When the mark ( ) is displayed
in LCD screen, replace battery.
No
* Check the contact point of CN-DISP 1, 2 connector & Re connector.
* Check display PCB Assembly
- Voltage between CN-DISP1 - should be DC +5V,
- If problem still persists, Replace display PCB
